Animations for Registers and Elements

isa_manim.isa_animate.register_animate.decl_register declares registers by fading in all provided register objects.

isa_manim.isa_animate.register_animate.replace_register replaces one existing register with a new register by transform.

An example for decl_register and replace_register is as below:

Source code: test_reg_animation.py

isa_manim.isa_animate.register_animate.read_elem reads one data element from one register by fading the provided element in the specified position.

isa_manim.isa_animate.register_animate.assign_elem assigns one data element to one register by moving the data element to the specified location related to the provided register.

It is not required that the target element must share the same shape and color as the origin element.

An example for read_elem and assign_elem is as below:

Source code: test_elem_animation.py

See isa_manim.isa_objects.reg_unit.RegUnit.get_elem_pos and isa_manim.isa_objects.elem_unit.ElemUnit.get_elem_pos for detail about how to index one element within one register unit or one element unit.

isa_manim.isa_animate.register_animate.replace_elem replaces the existing data element with a new data element by transform.

The above functions generate a sequence of animations, but they do not register animation to Manim unless play() is applied on the result values

register_animate

Animation with Registers and Elements.

assign_elem(old_elem, new_elem, vector, index, reg_idx, offset)

Assign one element to the register. Move element to the specified location related to the register.

Instead of move animation, this function uses transform animation. new_elem can use different width, color, and value from the old_elem.

Parameters:

Name	Type	Description	Default
old_elem	ElemUnit	Element object before animation.	required
new_elem	ElemUnit	Element object after animation.	required
vector	RegUnit	Register object.	required
index	int	Index of element.	required
reg_idx	int	register index.	required
offset	int	Offset of lowest bit.	required

Returns:

Type	Description
Animation	Animation to assign an element to a register.

decl_register(*registers)

Declare registers. Fadein a list of register objects.

Parameters:

Name	Type	Description	Default
registers	List[Union[RegUnit]]	List of registers.	()

Returns:

Type	Description
Animation	Animation to declare registers.

read_elem(vector, elem, index, reg_idx, offset)

Read specified element from one register. Fade in element at the specified position related to the register.

Parameters:

Name	Type	Description	Default
vector	RegUnit	Object of the register.	required
elem	ElemUnit	Object of the element.	required
index	int	Element index.	required
reg_idx	int	Register index. Used only for two-dimension register units.	required
offset	int	Offset of lowest bit.	required

Returns:

Type	Description
Animation	Animation to read an element from a register.

replace_elem(old_elem, new_elem, offset)

Replace exist element with a new element. The new element is right-aligned with the existed element. offset specifies the gap between the LSB of two registers, which can be positive or negative.

Parameters:

Name	Type	Description	Default
old_elem	ElemUnit	Object of the old element.	required
new_elem	ElemUnit	Object of the new element.	required
offset	int	Offset of lower bits.	required

Returns:

Type	Description
Animation	Animation to declare registers.

replace_register(old_reg, new_reg, offset)

Replacing exist register with a new register. The new register is right-aligned with the old register. offset specifies the gap between the LSB of two registers, which can be positive or negative.

Parameters:

Name	Type	Description	Default
old_reg	RegUnit	Object of the old vector.	required
new_reg	RegUnit	Object of the new vector.	required
offset	int	Offset of lower bits.	required

Returns:

Type	Description
Animation	Animation to replace registers.
